DT Rosetta IR SB D

Double Top Series
  • Sale
  • Regular price $2,495.00 USD


SERIAL NUMBER 19091641ROIRSB4D

Individually Handvoiced | Dreadnought with Soundport & Beveled Armrest | Double Top Soundboard | Solid Indian Rosewood Back & Sides

The Double Top Series encompasses what Maestro Guitars is all about; fusing innovation and traditional building techniques to make boutique instruments accessible to everyone. Maestro Guitars is proud to be the first and only builder to offer Double Top guitars off-the-rack. Made using soundboards with Nomex Honeycomb at its core, these guitars are known for its incomparable projection, responsiveness, and clarity.






INDIVIDUALLY HANDVOICED

Though bracing patterns affect the tonal characteristics of an acoustic guitar, there is no formulaic way of guaranteeing the best tone. Every material is different, especially the Double Top soundboards, that is why we take time to individually voice every Double Top Series guitar to deliver an instrument that has a very delicate response, rich in projection, and full of character.



DOUBLE TOP SOUNDBOARD

The soundboard of the Double Top Series is made of two thin layers of wood with a Nomex Honeycomb core, making the top very light yet very strong which result to an increased overall projection. Offered by very few builders as a custom option, we have been making this exclusive feature available off-the-rack since 2013.



HIGH FIDELITY SOUND

Aside from the rich projection, the Double Top Series boasts of clarity and fidelity like no other. With the right balance of projection, fundamentals, and overtones, these guitars are perfect for those who are looking for a clean recording sound without compromising character and responsiveness.



ICONIC DESIGN, MODERN APPOINTMENTS

Available with our signature CSB options – Florentine Cutaway, Soundport & Beveled Armrest – these guitars standout as they offer something that you rarely see off-the-rack. Aside from the playing comfort that the Beveled Armrest offers, the Soundport brings you to another level of expression and inspiration as it allows you to hear in detail every nuance of your playing.




SPECIFICATIONS

SERIAL NUMBER 19091641ROIRSB4D
SHAPE Dreadnought
SOUNDBOARD Double Top
BACK & SIDES Solid Indian Rosewood
SIGNATURE OPTIONS Soundport & Beveled Armrest
ROSETTE Rosewood with Abalone
BINDING Rosewood
PURFLING Abalone
LINING Reversed Kerfing
BRACING Modified X Brace
BRACING MATERIAL Quarter-Sawn Sitka Spruce
NECK Carbon Fiber Reinforced Khaya Mahogany
NECK JOINT Dovetail
FINGERBOARD Ebony
FINGERBOARD BINDING Rosewood
BRIDGE Ebony
NUT & SADDLE MATERIAL Unbleached Bone
BRIDGE PINS Ebony
HEADSTOCK STYLE Modern Maestro
MACHINE HEADS Grover Rotomatic 18:1
STRINGS Elixir Phosphor Bronze Nanoweb Light .012 – .053
FINISH Polyurethane Super High Gloss
SETUP PLEK Setup
CASE Premium Polycarbonate Hardcase

DIMENSIONS

LENGTH 1040 mm
BODY LENGTH 507 mm
LOWER BOUT 400 mm
WAIST 280 mm
DEPTH 110 mm
SCALE LENGTH 650 mm
NUT WIDTH 44 mm
STRING SPACING – NUT 36.5 mm
AVE. STRING SPACING – NUT 7.3 mm
STRING SPACING – SADDLE 54.4 mm
AVE. STRING SPACING – SADDLE 10.89 mm
FINGERBOARD RADIUS 14″
NECK THICKNESS – NUT 24 mm
NECK THICNKESS – 12th FRET 34 mm
